Produk ini mendukung sistem redundant sehingga tetap beroperasi saat salah satu controller gagal.
Kompatibel dengan BACnet dan Modbus, dapat diatur tanpa menghentikan sistem, terhubung ke monitoring pusat, dan tetap berjalan mandiri jika pusat mengalami gangguan.
| Item | Specification | |
|---|---|---|
| Power supply | Rated voltage | 100–240 V AC, 50/60 Hz |
| Operating voltage | 85–264 V AC, 50/60 Hz ± 3 Hz | |
| Inrush current | 20 A max. (100 V AC), 40 A max. (240 V AC) | |
| Power consumption | 30 VA max. | |
| Leakage current | 0.2 mA max. (100 V AC), 0.5 mA max. (240 V AC) | |
| RAM and RTC backup | Powered by lithium batteries (not rechargeable) | |
| CPU | 32-bit | |
| Memory capacity | 256 MB SDRAM, 32 MB Flash ROM, 2 MB SRAM | |
| Communication | Ethernet (LAN 0)
– Protocol |
BACnet/IP |
| – Communication speed | 100 Mbps / 1000 Mbps | |
| – Communication method | Autonegotiation, Auto MDI/MDI-X | |
| Ethernet (LAN 1, LAN 2) –
– Protocol |
Proprietary | |
| – Communication speed | 100 Mbps | |
| – Communication method | Auto MDI/MDI-X | |
| – Number of connectable devices | Max. 20 Advanced Remote I/O Modules (per Advanced Controller) | |
| RS-485
– Protocol |
BACnet MS/TP or Modbus Note: Selectable via software settings. |
|
| – Number of channels | 2 | |
| – Communication speed | • BACnet MS/TP: 9.6, 19.2, 38.4, 76.8 kbps • Modbus: 4.8, 9.6, 19.2, 38.4, 76.8 kbps |
|
| – Communication distance | 1,000 m max. | |
| – Number of connectable devices | For BACnet MS/TP: max. 50 (Azbil only) / 31 (third-party) For Modbus RTU/ASCII: max. 31 per channel |
|
| Main material and color | Cover | Modified PPE, black |
| DIN holder | Molded polyacetal resin | |
| Weight | 1.1 kg | |
