| Specifications / Testing Machine Model | MGW-5000 | MGW-6500 | MGW-10000 |
| Maximum test force ( KN ) | 5000 | 6500 | 10000 |
| Relative error of test force indication | ≤± 1% of the indicated value | ||
| Test force measuring range | 2%-100%FN | ||
| Stretching distance ( mm ) | 3400 | 3500 | 3500 |
| Piston stroke ( mm ) | 200 | 200 | 200 |
| Displacement measuring range ( mm ) | 0-200 | 0-200 | 0-200 |
| Displacement measurement accuracy | ± 1% | ||
| Dimensions of the main unit (L * W * H) mm | 3400*800*800 | 3600*800*800 | 3700*1000*1000 |
Alat Uji Jangkar MGW-6000 Anchorage Testing Machine
