| No. |
technical name |
technical parameter |
| 1 |
Maximum test force ( kN ) |
2000 |
| 2 |
Test force measurement range |
4%-100% of the maximum test force |
| 3 |
Relative error of test force indication |
≤ ±1% of the indicated value |
| 4 |
Maximum distance between upper and lower platens ( mm ) |
420 |
| 5 |
Upper and lower platen size ( mm ) |
Φ300 |
| 6 |
Piston stroke ( mm ) |
0-100 |
| 7 |
Maximum speed of piston no-load rising ( mm/min ) |
about 30 |
| 8 |
Column clear spacing ( mm ) |
368×318 |
| 9 |
Oil pump motor power ( kW ) |
1.5 |
| 10 |
Lifting motor power ( kW ) |
0.55 |
| 11 |
Dimensions of the main body of the testing machine (length x width x height) ( mm ) |
590×580×2050 |
| 12 |
Dimensions of the dynamometer ( LxWxH ) ( mm ) |
550×610×1110 |
| 13 |
Host mass ( kg ) |
about 1470 |
| 14 |
Dynamometer mass ( kg ) |
about 400 |
