Item
Specification
Machine dimension
500*500mm
Max. Loading
0~10kg
Vibration direction
Up and down; right and left; front and back (switch automatically)
Amplitude
0~5mm (random)
Sweep frequency
1—600Hz (adjustable; can be customized to 3000Hz)
Maximum acceleration
10G
Function
frequency adjustable; programmable; time control
Accuracy
0.1Hz
Programmable function
1~600Hz
Group 1 – 8 can set different frequency and time, cyclic
Vibration waveform
Sine wave (half wave / full wave)
Time control
Adjustable, unit: seconds
Output
To connect U Flash Dish for output curve graph
Power
220V; 50Hz; 0.75KW
Test Method
the frequency of 10-55Hz, the amplitude of 0.35mm, each direction of the frequency sweep cycle for 10 times. After testing the electrical performance OK
