Pantau konsumsi energi dan peralatan industri menggunakan data logger 15-channel ini untuk mendeteksi serta menangani masalah pada sistem HVAC, mesin, dan sistem industri lainnya secara cepat dan efisien.
| Operating Range | With Alkaline Batteries: -20°C to 50°C (-4°F to 122°F)With Lithium Batteries: -40°C to 60°C (-40°F to 140°F) |
|---|---|
| Sensor Inputs | Supports three FlexSmart multi-channel modules and up to six Smart Sensors (each sensor may include multiple parameters or channels). |
| Sensor Connectors | Six RJ-12 Smart Sensor jacks and three FlexSmart module slots. |
| Communication | RS-232 via 3.5 mm serial port and/or 9-pin D-Sub connector. |
| Dimensions | 15.6 cm x 8.4 cm x 4.6 cm (6.13″ x 3.31″ x 1.81″) |
| Weight | 435 g (15.23 oz) with batteries 238 g (8.33 oz) without batteries |
| Memory | 512 KB nonvolatile flash data storage. |
| Memory Modes | Stop when full or wrap when full. |
| Operational Indicators | Six LED indicators for logging and sensor network status. |
| Logging Interval | User-selectable from 1 second up to 18 hours (2-second minimum for two-channel S-FS-TRMSA operation). |
| Sensor Excitation | 12 V DC at 200 mA total, with user-programmable warmup time per channel. |
| Battery Life | Typical one-year operation with up to 75 mA excitation, using a 10-minute or longer logging interval and 1-second warmup time. |
| Battery Type | Eight AA alkaline batteries included (operating range: -20°C to 50°C / -4°F to 122°F).Optional AA lithium batteries available for extreme conditions down to -40°C (-40°F) and up to 60°C (140°F). |
| External Power | Supports optional 13.6 V DC regulated AC wall adapter. Internal batteries may remain installed. Alternatively, a 9–12 V DC regulated wall adapter or automotive battery can be used. Removing internal batteries is recommended to prevent discharge. |
| Time Accuracy | 0–2 seconds for the first data point and ±5 seconds per week at 25°C (77°F). |
| Logging Mode | Immediate start, timed delay, or trigger (button-push) start. Supports sampling intervals for selected sensors. |
| Data Communication | View current readings while logging, read out data during logging, or retrieve data when logging has stopped. |
