Fitur MX801
- Kompatibel dengan sensor Konduktivitas, CTD (konduktivitas/suhu/kedalaman) yang dapat dipertukarkan, dan sensor DO (dijual terpisah) – tukar sensor untuk aplikasi berbeda
- Bluetooth, untuk memudahkan konfigurasi logger dan pembongkaran data
- Mudah diterapkan, dapat tenggelam sepenuhnya (MX801)
- Diameter logger kurang dari 2 inci
- Pembongkaran data lebih cepat melalui Bluetooth 5.0
- Fitur pendeteksi air menunjukkan kapan logger keluar dari air (MX801)
- Hubungkan dua sensor ke satu logger untuk mendapatkan pengukuran seperti DO yang disesuaikan dengan salinitas secara langsung, tanpa memerlukan pasca-pemrosesan
- Kalibrasi terpandu memastikan data akurat
- Baterai yang dapat diganti pengguna
-
Spesifikasi MX801
- Operating Range
-
-40° to 50°C (-40° to 122°F), cannot be frozen in ice
- Radio Power
-
1 mW (0 dBm)
- Transmission Range
-
Approximately 30.5 m (100 ft) line-of-sight
- Wireless Data Standard
-
Bluetooth 5
- Number of sensors that can be connected
-
2
- Maximum Cable Length
-
120m (400 ft)
- Logging Rate
-
5 second to 18 hours
- Logging Modes
-
Fixed interval (normal or statistics), burst, or multiple intervals with up to 8 user-defined logging intervals and durations, with pause and repeat options
- Start Modes
-
Immediate, next interval or date & time
- Stop Modes
-
Memory full, never stop (overwrite oldest data), date & time, or after a set logging period
- Water Detect
-
Events are logged when logger is submerged or removed from the water (MX801 only)
- Time Accuracy
-
±1 minute per month 0° to 50°C (32° to 122°F)
- Battery
-
Four AA, 1.5 V lithium batteries, user replaceable
- Battery Life
-
With W-CTD or W-CT sensors: 2 years, typical with 1-minute logging interval or slowerWith W-DO sensor: 1-year, typical with 5-minute logging interval or slowerFaster logging or statistics sampling intervals, entering burst logging mode, excessive readouts, and remaining connected with the app will impact battery life
- Memory
-
730,000 measurements, divided between channels (4 Mbyte memory)
- Data Download Time (with Bluetooth 5+ devices)
-
Full memory: Approximately 3.5 minutes120,000 measurements: 1 minuteMay take longer the further the device is from the logger
