Fitur
- Intel® Skylake/Kabylake-U processor
- 1-Ch DDR4 SODIMM, Max up to 16GB
- 1*HDMI, 1*LVDS, Audio 功放
- 2*GbE LAN, 4*USB3.0, 2*USB2.0
- 4*COM, 1*JHC高速总线规范扩展接口EIO
- 1*Mini PCIe, 1*SIMcard slot, support GPS/WiFi/LTE/GSM
- 2*SATA3.0 6Gbps, 1*mSATA用于存储
- 可选支持TPM 2.0安全加密，iVpro technology
- DC 9~36V wide voltage
Spesifikasi Lengkap
System | CPU | Celeron 3855U | Celeron 3865U | I3-6100U | I3-7100U | I5-6200U | I5-7200U | I7-6500U | I7-7500U | |
| Cores | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | ||
| Threads | 2 | 2 | 4 | 4 | 4 | 4 | 4 | 4 | ||
| Frequency(GHz) | 1.6 | 1.8 | 2.3 | 2.4 | 2.3 | 2.5 | 2.5 | 2.7 | ||
| System Memory | 1-Ch DDR4,Support 2133MHz SODIMM MAX 16GB | |||||||||
| Expansion | 1*Mini PCIe(full size) with PCIe X1+USB,with SIM slot,support 4G/LTE/GSM/Wifi/BT/GPS | |||||||||
| Graphics | Intel® Gen.9 HD Graphics; HDMI & 48Bit LVDS,support 2displays,support Intel hd video and wireless display | |||||||||
| Audio | Realtek ALC662VD controller, Support 5.1 channel | |||||||||
| LAN | 2*Intel I210AT PCIe Gig. Ethernet, 10/100/1000Mbps | |||||||||
| Keyboard & Mouse | USB Keyboard and mouse | |||||||||
| Storage | 2*SATA3.0 port(6.0Gbps);1*mSATA(full size), support AHCI | |||||||||
| EIO | JHCTECH Standard specification interface, with LPC、SM Bus、2*PCIeX1 | |||||||||
| Internal I/O | 1*USB2.0 Wafer; 1*RS232/422/485 wafer; 1*48Bit LVDS; 1*80pin EIO; 1*FAN; 2*Amplifier out; 1*Capacitive touch screen wafer; 1*Resistance touch screen wafer; 1*SM Bus wafer | |||||||||
| Rear I/O | 2*RJ45 GbE LAN（with LED); 4*USB3.0 Type A; 2*RS232/422/485; 1*Audio out 3.5mm Phone jack; 1*HDMI | |||||||||
| Switch | 1*2-pin Remote SW; 1*AT/ATX SW; 1*Clear CMOS SW | |||||||||
| LED | 1*Power LED; 1*HDD LED; 3*CPU Temp.LED(Red is warning, Yellow is high, Green is normal) | |||||||||
| Power Supply | DC 9~36V Input,3-pin,Comsuption: 12V@3.75A (I7-7500U, 4GB, 64GB SSD, 1TB HDD) | |||||||||
| Watchdog Timer | Watchdog timeout programmable via software 1 to 255 second | |||||||||
| OS Support | Windows 7; Windows 10; Linux Fedora; Ubuntu (Note: Gen.7th Intel® Kabylake-U processors don’t support Windows 7) | |||||||||
Mechanical & Environmental | Dimension | (W*H): 190*115mm | ||||||||
| Thickness | Front：17.9mm，Rear:9.5mm，PCB:1.6mm | |||||||||
| Operating Temperature | 0°C~60°C | |||||||||
| Storage Temperature | -40°C~85°C | |||||||||
| Storage Humidity | 10~90%@40°C, Non-condensing | |||||||||
| Certification/EMC | CE & FCC CLASS B | |||||||||
