Fitur
- Intel® Skylake/Kabylake-U CPU
- 2-Ch DDR4, Onboard 4GB+SODIMM, up to16GB
- 1*DP, 1*VGA, 1*Smart Display, 3 display
- 2*LAN(M12）, 5*USB(2*M12), with internal dongle
- 1*CONSOLE RS232(RJ45)
- 1*SATA3.0 ，1*mSATA（Opt.）
- 4*Mini PCIe(1*Optional mSATA), support GPS/WiFi/LTE/4G
- MLU220T-MXM AI accelerate，16TOPS (INT8）
- EN50155, E-Mark certification, support TPM2.0
- Railway power DC 110V
Spesifikasi Lengkap
| CPU | Intel® Skylake/Kabylake-U Corei3/i5/i7 series CPU |
| System memory | 2-ch DDR4, support 2133MHz, on board 4GB+1*SODIMM, up to 12GB |
| Graphics | Intel® Gen. 9 HD Graphics，support 3 display DP max. res. 4096*2160@60Hz Smart Display max. res. 1920*1200@60Hz VGA max. res. 1920*1200@60Hz |
| LAN | 2*Intel® I210AT PCIe Gig. Ethernet, 10/100/1000Mbps, M12 X-Coded connector |
| Storage | 1*SSD/HDD SATA bay; 1*mSATA (SATA+USB); |
| I/O ports | 2*Gig-LAN (M12 X-Coded) 2*USB3.0 Type A, 2*USB2.0 (M12 A-Coded), 1*USB2.0 Type A 1*Console RS232（RJ45） 1*VGA + 1*DP + Smart Display |
| Expansion | 2*Mini PCIe with PCIe X1+USBsignal, 2*SIM slot, support 2*4G/LTE/Wifi/BT/GPS 1*Mini PCIe with SATA+USB signal，support mSATA 1*Mini PCIe with PCIe + USB signal |
| AI chip | MLU220T-MXM AI accelerate，16TOPS（INT8） |
| LED | 1*Power LED, 1*HDD LED, 3*CPU Temp. LED (Red is warning, yellow is High, Green is normal) |
| Control SW | 1*Power button, 1*Remote SW signal, 1*AT/ATX SW, 1*Clear CMOS SW |
| Security | Infineon TPM2.0 |
| Power Supply | DC 110V input, 4-pin connector(M12), TDP: TBD) |
| Watchdog Timer | Watchdog timeout programmable via software1 to 255 second |
| OS Support | Linux Fedora, Ubuntu |
| Structure | Aluminum chassis, Silver stainless steel wire drawing frame |
| Color | Silver + Grey |
| Mounting | Rack installation |
| Dimension | (W*H*D)：430*283.05*44.5mm |
| Net weight | TBD |
| Operating temperature | EN50155 TX: -40～60℃ |
| Storage Temperature | -40°C~85°C |
| Storage Humidity | 10~90%@40°C, Non-condensing |
| Vibration | MIL-STD-810G, EN50155 |
| Shock | MIL-STD-810G, EN50155 |
| EMC/ Certification | EN50155 & E-Mark & CE & FCC Class B |
