FEATURES
- Application
- Manufacturing
- Distribution
- Features
- Rugged
- Versatile
- Smart Dock
DIMENSIONS
- Overall Dimensions
- 31.8 x 26 x 6.2 cm
- 12.5 x 10.3 x 2.4 in
NETWORK
- Bluetooth Specifications
- v2.0
SOFTWARE & FIRMWARE
- Operating System
- Windows Embedded Compact
- Windows Embedded Standard
- Windows 7
- Windows 10 IoT Enterprise
MEMORY & DATA
- Memory
- 4 GB RAM
HARDWARE
- Display Resolution
- 1024 x 768
- Display Size
- 12.1 in
- 30.7 cm
- Processor
- 1.5 GHz Dual Core Intel Atom E3826
- Connection Interface
- RS-232
- RF Antenna
- USB
- Audio
- CANbus
ENVIRONMENTAL
- Operating Temperature
- – 30 – 50 °C
- – 22 – 122 °F
- Storage Temperature Range
- – 22 – 122 °F
- – 30 – 50 °C
- Cold Storage
- Cold storage defrosters
- Operating Humidity
- 5 – 95 %
STANDARDS & APPROVALS
- Vibration Resistance
- MIL-STD-810F
SERVICE TERMS
- Warranty Duration
- 1 yr
OTHERS
- Operating System Type
- Windows
- Touchscreen Type
- Capacitive- Optimized for Touch
- Resistive-Touch and Stylus
- Keyboard
- Touchscreen only
- Network
- WLAN/WWAN
- Screensize
- 12 inch
