Spesifikasi
Spesifikasi
| Model | QC-639C | QC-639D |
|---|---|---|
| Test type | IZOD、CHARPY | |
| Start impact Angle | 150° | |
| Test Capacity | Izod 1-12J | Izod 1-25J |
| 20-80% of the max. capacity is the suggested test range. | ||
| Feature | 1. Big indicator board for reading the impact energy directly. 2. Standard pointer for users to read impact angle easily. 3. Equipped with lever device to ensure the machine positioning accuracy. 4. Provide impact area and collect box to increase the safety and reduce the cleaning time. 5. Able to change vises for Izod and Charpy to satisfy different test standards. | |
| Accessories | Calibration table for hammer, Manual, Energy Calculating Software, Hex Wrench Set | |
| Optional | 1. Impact hammers for different energy test and different vises 2. QC-640 Impact Specimen V-notcher | |
| Dimension | 90 × 30 × 70 cm | 95 × 38 × 76 cm |
| Weight | 100 kg | 160 kg |
