Fitur
- Kombinasi kecepatan dan arah angin
- Low Starting threshold
- Desain yang padat dan ringan
- Pemasangan yang mudah
Aplikasi
- Pemantauan lingkungan
- Jembatan dan Terowongan
- Pembangkit listrik tenaga surya dan angin
- Penilaian sumber daya angin
- Stasiun cuaca otomatis
- agrikultur
Spesifikasi
|
Item
|
Technical Specification |
|||
| Wind Speed | Wind Direction | |||
|
Range
|
0-45m/s(current or voltage ouput),
0-70m/s(pulse,RS485,RS232 output)
|
0-360° | ||
|
Resolution
|
0.1m/s
|
1° | ||
|
Accuracy
|
±(0.3+0.03V)m/s ,V is current wind speed |
≤±3° | ||
|
Acquisition Cycle
|
3s | |||
| Starting wind speed | 0.5m/s | |||
|
Limited wind speed
|
75m/s | |||
|
Supply
|
5V(only for digital output),12-24VDC | |||
|
Output Signal
|
RS485,4-20mA,0-5V,RS232,pulse(NPN,only for wind speed) | |||
| Operating Temperature | -40℃-+70℃ | |||
| Ingress Protection | IP65 | |||
| Main material | Aluminum alloy and ABS | |||
| Storage | 10-60℃@20%-90%RH | |||
| Cable length | Default 2.5m,other length is optional | |||
| Installation bracket | attached | |||
| Weight(unpacked) | 700g | |||
