Fitur
- Probe pendeteksian gas sensitivitas tinggi
- Respon cepat
- Akurasi tinggi
- Stabilitas yang baik
- Tahan lama
- Output digital dengan parameter kelembaban suhu dan konsentrasi CO3
Aplikasi
- Pemantauan kualitas udara
- Smart home
- Warehouse
- Public place
- Pemantauan kemanan lingkungan
- Peternakan
Spesifikasi
|
Item |
Technical Specification |
| Range(CO concentration) |
0-2000ppm |
| Range(temperature ) |
-40-+80℃ only for digital output |
| Range(humidity ) |
0-100% only for digital output |
| Accuracy(CO concentration) |
10%FS @25℃ |
| Resolution(CO concentration) |
0.1ppm |
| Supply |
12-24VDC |
| Output |
4-20mA,0-5V,0-10V,RS485 |
| Power Consumption |
<0.25W |
| Warm Up Time |
3min |
| Response Time |
<2s |
| Repeatability |
<±10%FS |
| Zero drift |
<10ppm |
| Operating Temperature |
-20℃-+60℃@15-80%RH |
| Storage |
-40-70℃@20%-90%RH |
| Shell Material |
ABS |
| Installation |
Wall-mounted |
| Dimension |
110*85*44mm |
