| Item | Technical Specification |
| Sampling object | PM1.0, PM2.5, PM10 Concentration |
| Range | 0-1000ug/m3 |
| Accuracy | ±3%FS@25℃ |
| Supply | 5VDC,12-24VDC |
| Output | 4-20mA,0-5V,0-10V,RS485 |
| Power Consumption | <50mA@24V(4-20mA) |
| Warm Up Time | 3min |
| Response Time | <90s |
| Temperature Drift | ≤0.2%FS/℃ |
| Stability | <±2%fs |
| Repeatability | <±1%fs |
| Operating Temperature | -20℃-+50℃@15-80%RH |
| Storage | -40-60℃@20%-90%RH |
| Shell material | ABS |
