Sensor Suhu Dan Kelembaban, Ambient Sensor, Humidity Sensor
RK330-02 Sensor Suhu & Kelembaban Atmosfer adalah pengukuran
profesional suhu udara dan kelembaban relatif. Elemen sensor
adalah IC suhu dan kelembaban digital. Sensor built-in di tempat
penampungan tahan air dan anti-UV. Ini banyak digunakan di
bidang pertanian, kehutanan, meteorologi serta ruang iklim,
pergudangan dan tempat-tempat lain.
| Item | Technical Specification | |
| Temperature | Humidity | |
| Range | -30-+70℃,0-50℃ | 0-100%RH |
| Accuracy | ±0.3℃@25℃ | ±3%RH(10%-90%) |
| Repeatability | ±0.1℃ | ±0.1%RH |
| Long-term Stability | <0.04℃/year | <0.5%RH/year |
| Response Time | <1s | |
| Supply | 5VDC, 12-24VDC | |
| Output Signal | 4-20mA,0-5V,RS485 MODBUS(RTU) | |
| Display(universal) | LCD is optional | |
| Current Consumption | <20mA | |
| Operating Temperature | -40℃-+70℃ | |
| Ingress Protection | IP65 | |
| Storage | 10-60℃@20%-90%RH | |
| Weight(unpacked) | 170g | |
| Dimension | 117*86*41mm | |
| Shelter material | ABS | |
