Specifications
| Model | WDS-01,02,03,05,1,2,3,5 |
| Structure | Single column double spaces |
| Max. Load(kN) | 0.1, 0.2, 0.3, 0.5, 1, 2, 3 ,5 |
| Material | All aluminum alloy surface spray painting shell |
| Load accuracy | ISO 7500 Class 0.5 |
| Load range | 0.2%～100%F·S |
| Load resolution | 1/ 50000 |
| Resolution of displacement | 0.01mm |
| Test speed(mm/min) | 1-500 stepless arbitrary setting |
| Speed accuracy | within ±1% set speed |
| E-Tensile space(mm) | 600（can be customized） |
| E-Compression space(mm) | 600（can be customized） |
| D-Test width(mm) | 100 |
| F-Beam travel
distance(mm) |
772 |
| H-Workbench thickness(mm) | 26 |
| G-Base height(mm) | 158 |
| Power supply | AC220V±10%，50Hz/60Hz(can be customized) |
| Video show | https://youtu.be/io3tjHnMmDU |
