Specifications
| Model | WDW-30ET | WDW-50ET | WDW-100ET |
| Max. Load(kN) | 30 | 50 | 100 |
| Load accuracy | Class 0.5 | ||
| Load range | 0.2%～100%F·S | ||
| Load resolution | 1/500000 | ||
| Resolution of deformation | 0.04um | ||
| Accuracy of displacement | Within±0.5%of indicating load | ||
| Resolution of displacement | 0.01mm | ||
| Test speed(mm/min) | 0.05-1000 stepless arbitrary setting | ||
| Speed accuracy | within ±1% / ±0.5% of set speed | ||
| E-Tensile space(mm) | 770 | 770 | 650 |
| E-Compression space(mm) | 1000 | 1000 | 1000 |
| D-Test width(mm) | 450 | 450 | 550 |
| F-Beam travel distance(mm) | 1100 | ||
| Power supply | AC220V±10%，50Hz/60Hz (can be customized) | ||
