DIMENSIONS
- Overall Dimensions
- 3.8 in x 2.2 in x 1.6 in
- 95.7 mm x 56 mm x 39.4 mm
SCANNING SPECIFICATIONS
- Pitch
- ±45°
- Motion Tolerance
- Up to 584 cm 230 in/second
- Decode Capability
- 1D/2D
- Skew
- ±60°
- Scanning Range
- Standard range SR
- Brightness
- 0 to 100,000 lux
NETWORK
- Bluetooth Specifications
- 2.4 GHz to 2.5 GHz ISMNEWLINEBand Adaptive Frequency HoppingNEWLINEBluetooth® v. 5.0: Class 1;
ENVIRONMENTAL
- Operating Temperature
- -20°C to 50°C
- -4°F to 122°F
- Storage Temperature Range
- -4°F to 140°F
- -20°C to 60°C
- Operating Humidity
- 0% to 95% relative humidity non- condensing
STANDARDS & APPROVALS
- Protection Ratings
- IP54
- Drop Specifications
- 36 1.5 m 4.9 ft drops to concrete
SERVICE TERMS
- Warranty Duration
- Two-year factory warranty Note: Battery warranty is one year.
OTHERS
- Power Connector Type
- Cordless
