| vertical loading section |
| Specifications / Testing Machine Model |
YAW-5000J |
YAW-10000J |
YAW-15000J |
YAW-20000J |
YAW-30000J |
| Maximum test force ( KN ) |
5000 |
10000 |
15000 |
20000 |
30000 |
| Relative error of test force indication |
≤± 1% of the indicated value |
| Test force measuring range |
1%-100%FN |
| Compression space ( mm ) |
900 |
1500 |
1500 |
1500 |
1500 |
| Piston no-load maximum speed ( mm/min ) |
50 |
40 |
40 |
40 |
40 |
| Piston stroke ( mm ) |
150 |
300 |
300 |
300 |
300 |
| Displacement measuring range ( mm ) |
0-150 |
0-300 |
0-300 |
0-300 |
0-300 |
| Displacement measurement accuracy |
± 1% |
| Deformation measurement |
Four grating digital displacement sensors measure the vertical deformation of the sample |
| Four grating digital displacement sensors measure the radial deformation of the sample |
| Upper and lower platen size (L * W) mm |
700*800 |
1050*1050 |
1200*1200 |
1350*1350 |
1500*1500 |
| Beam lifting speed ( mm/min ) |
170 |
200 |
200 |
200 |
200 |
| Dimensions of the host about mm |
1255*1145*3900 |
3700*1900*4900 |
5000*2340*5000 |
5000*2340*5150 |
5000*2500*5300 |
