FEATURES
- Audio Capability
- Access to speaker and microphone
- Application
- Healthcare
- Camera
- Access to iPod 5c front and back cameras Adaptus
- Buttons
- Access to iPod/iPhone5/5s/5c Home button
- Left and right side scan buttons
- Sleep/wake button
DIMENSIONS
- Overall Dimensions
- 145.6 mm x 73.3 mm x 33 mm
- 5.7 in x 2.9 in x 1.3 in
SCANNING SPECIFICATIONS
- Decode Capability
- OCR
- 2D
- 1D
- Postal
SOFTWARE & FIRMWARE
- Development Environment
- Captuvo SDK for Apple® iOS 6 and 7
HARDWARE
- Connection Interface
- UART between SL22/42 Apple® iOS device
- USB/UART between SL22/42 & PC
ENVIRONMENTAL
- Operating Humidity
- 5% to 85% relative humidity, non-condensing
- Operating Temperature
- 0°C to 35°C
- 32°F to 95°F
- Storage Temperature Range
- -20°C to 45°C
- 4°F to 113°F
STANDARDS & APPROVALS
- Drop Specifications
- Designed to withstand multiple 1.2 m 4 ft drops to concrete, all axis under room temperature
- Protection Ratings
- IP54
SERVICE TERMS
- Warranty Duration
- 1 year factory warranty
OTHERS
- Data Capture
- Imager
