Fitur
- Dua prinsip operasi diadopsi: induksi magnetik (ferrous) dan arus eddy (nonferrous) untuk melakukan pengukuran non-destruktif
- Kalibrasi titik nol dan kalibrasi dua titik untuk memperbaiki kesalahan sistem pada probe
- Menampilkan dua mode kerja: LANGSUNG dan BATCH & dua cara pengukuran: LANJUTKAN dan TUNGGAL
- Statistik meliputi mean, maksimum, minimum, nomor tes dan standar deviasi.
- Pengenalan media secara otomatis.
- Memori 600 data
- Penghapusan data saat ini, data yang dikalibrasi, data batas dan semua data yang disimpan.
- Indikasi baterai lemah dan alarm kesalahan
- Buzz selama operasi untuk indikasi
- Shutdown otomatis atau manual
| Standard Delivery | Optional Accessory | |
| Main unit | 1 | Connecting cable |
| Substrate | 2 | Dataview |
| Calibration foil | 1 | |
| AAA 1.5V battery | 2 | |
| TIME certificate | 1 | |
| Warranty card | 1 | |
| Instruction manual | 1 |
Spesifikasi
| Probe types | F | N | |
| Working principle | Magnetic induction | Eddy current | |
| Measuring range | 0-1250 μm | 0-1250 μm, 0-40μm (for chrome plate on copper) | |
| Minimum resolution | 0.1μm | ||
| Tolerance | Zero point calibration |
±(3%H+1) μm | ±(3%H+1) μm |
| H means the thickness of tested piece
|
|||
| Two points calibration |
±{(1-3)%H+1}μm | ±{(1-3)%H+1}μm | |
| H means the thickness of tested piece
|
|||
| Measuring condition |
Min. curvature radius |
Convexity 1.5 mm | Convexity 3 mm |
| Min. area diameter |
Φ7 mm | Φ5 mm | |
| Critical thickness of the base |
0.5 mm | 0.3 mm | |
| Operating environment | Temperature: 0℃- 40℃ | ||
| Humidity: 20%-90% | |||
| No strong magnetic field | |||
| Power | 2 pcs AAA 1.5 V battery | ||
| Dimension | 110 x 50 x 23 (mm) | ||
| Weight | 100 g | ||
